Manufacturer: Cessna
Aircraft Model(s): 208B Caravan, 208A Caravan, 208 Caravan
Applicable Engines: PT6A-114, 114A
| QTY | DESCRIPTION | ITEM # |
| 1 | 3-Bladed Propeller | HC-B3TN-3AF/T10890CN-2 |
| 1 | Polished Spinner | D-4897-P |
| 1 | STC Paperwork | SA02181AK |
| QTY | DESCRIPTION | ITEM # |
| 1 | 3-Bladed Propeller | HC-B3TN-3AF/T10890CNK-2 |
| 1 | Polished Spinner | D-4897-P |
| 1 | Electric De-ice kit (prop) | 7931-5E2715-1 |
| *1 | Electric De-ice kit (airframe) * Only when replacing a McCauley | 7931-5E2715-3 |
| 1 | STC Paperwork | SA02181AK |
| QTY | DESCRIPTION | ITEM # |
| 1 | 3-Bladed Propeller | HC-B3TN-3AF/T10890CNB-2 |
| 1 | Polished Spinner | D-4897-2P |
| 1 | Anti-ice kit (prop) | 105014 |
| 1 | STC Paperwork | SA02181AK |
| DESCRIPTION | ITEM # | NOTES |
| Propeller with Start Locks | HC-B3TN-3AFY/T10890CN( )-2 | Available for all configurations. |
Applicable Models:
208, 208A, 208B
Specifications:
106 inch diameter 3-bladed, steel hub propeller
Diameter reduction allowable to 104 inches
Weight of Propeller = 146.7 lbs.
Weight of Spinner = 9.0 lbs.
Weight of De-ice = 2.8 lbs.
3000 hour / 5 year TBO
Replaces:
McCauley C703 – 106 inch diameter 3-bladed prop
Diameter reduction allowable to104 inches
Weight of Propeller = 117.0 lbs.
4000 hour / 6 year TBO
Hartzell HC-B3MN – 100 inch diameter 3-bladed composite prop
No diameter reduction allowable
Weight of Propeller = 134.7 lbs.
Weight of Spinner = 9.0 lbs.
Weight of De-ice = 2.8 lbs.
3000 hour /5 year TBO
Advantages:
Climb and cruise performance are as good as or slightly better than the McCauley C703 (+25ft/min, +3kts measured)
Take off distance unchanged
Substantial material for blade repairs
Most repairable blade avaialable for the Caravan
Notes:
Approved for landplane and seaplane
Standard installation of propeller, de-ice brushes/bracket
Common electrical hardware not included in the de-ice kit
