Manufacturer: Cessna
Aircraft Model(s): Cessna 180 (A-K)
Applicable Engines: O-470-50, O-550-F-TS, O-520-KAH, IO-520-D, IO-550-D

PDF:180(A-K)

Advantages:

  • Increased takeoff and climb performance
  • Lightest 3 blade available
  • Unlimited Life Blades
  • Top Prop Warranty to first overhaul

Order Part #C3F20165STP Kit (80″ Diameter) Includes:

  • Air Plains………………………………………………………………………………….180, 180(A-J)……………………………………………………………………………………….IO-520-D
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-C3YF-1N/NM8411-6/SM30
1Polished SpinnerC-3575-P
1STC Document SetSA04643CH



Order Part #C3F20161STP Kit (86″ Diameter) Includes:

  • PPONK……………………………………………………………………………………180, 180(A-K)…………………………………………………………………………………..O-470-50
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-C3YF-1N/NM8411/30
1Polished SpinnerC-3575-P
1STC Document SetSA04643CH



Order Part #C3F20166STP Kit (80″ Diameter) Includes:

    • Air Plains…………………………………………………………………………………180K………………………………………………………………………………………………IO-550-D
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-C3YF-1N/NM8411-6/SM30
1Polished SpinnerC-3575-P
1STC Document SetSA04643CH



Order Part #C3F20162STP Kit (82″ Diameter) Includes:

  • Texas Skyways……………………………………………………………………………180, 180(A-J)…………………………………………………………………………….O-550-F-TS
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-C3YF-1N/NM8411-4/SM30
1Polished SpinnerC-3575-P
1STC Document SetSA04643CH



Order Part #C3F20163STP Kit (82″ Diameter) Includes:

  • Kenmore Air Harbor………………………………………………………………………180(G-J)…………………………………………………………………………..O-520-KAH
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-C3YF-1N/NM8411-4/SM30
1Polished SpinnerC-3575-P
1STC Document SetSA04643CH



Order Part #C3F20164STP Kit (82″ Diameter) Includes:

  • Air Plains………………………………………………………………………………..180-180(A-J)…………………………………………………………………………………..IO-550-D
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-C3YF-1N/NM8411-4/SM30
1Polished SpinnerC-3575-P
1STC Document SetSA04643CH

Applicable Models: 180, 180 (A-K)

Specifications:

  • Applicable engines: O-470-50, O-550-F-TS, O-520-KAH, IO-520-D, IO-550-D
  • 2400 hour / 6 year TBO
  • 80″, 82″, or 86″ diameter 3-bladed aluminum hub propeller
  • 82″: 62.6 pounds (propeller and spinner)
  • 86″: 62.9 pounds (propeller and spinner)
  • NO RPM RESTRICTIONS
