Cessna 182, 182(A-R) Scimitar "Carbon Voyager" - Hartzell Propeller
North America:1 (800) 942-7767 International:+1 (937) 778-4200
Search

Manufacturer: Cessna
Aircraft Model(s): 182, 182(A-R)
Applicable Engines: O-470-50, IO-520-D, IO-550-D

PDF182, 182(A-R)

Advantages:

  • Increased takeoff and climb performance
  • Lightest 3 blade available
  • Unlimited Life Blades
  • Top Prop Warranty to first overhaul

Order Part # G3F20161STP (82″ Diameter) Kit Includes:

  • Peterson Perf. Plus………………………………………………………………………182(E-R)…………………………………………………………………………………..IO-550-D
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-G3YF-1N/NM8411-4/30
1Polished SpinnerD-4798-3P (182,182(A-G)) or D-4798-1P (182(H-R))
1STC Document SetSA04643CH



Order Part # G3F20162STP (82″ Diameter) Kit Includes:

  • P. Ponk Cessna……………………………………………………………………………..182(H-P)……………………………………………………………………………………..IO-520-D
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-G3YF-1N/NM8411-4/30
1Polished SpinnerD-4798-3P (182,182(A-G)) or D-4798-1P (182(H-R))
1STC Document SetSA04643CH

Order Part # G3F20163STP (80″ Diameter) Kit Includes:

  • John Jewell Cessna…………………………………………………………………..182, 182(A-R)…………………………………………………………………………….IO-520-D
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-G3YF-1N/NM8411-6/30
1Polished SpinnerD-4798-3P (182,182(A-G)) or D-4798-1P (182(H-R))
1STC Document SetSA04643CH



Order Part # G3F20164STP (80″ Diameter) Kit Includes:

  • John Jewell Cessna……………………………………………………………………..182, 182(A-R)…………………………………………………………………………………IO-550-D
  • Air Plains……………………………………………………………………………………………..182(H-P)………………………………………………………………………………………IO-550-D
  • Davis Aviation………………………………………………………………………………………182Q………………………………………………………………………………………….IO-550-D
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-G3YF-1N/NM8411-6/30
1Polished SpinnerD-4798-3P (182,182(A-G)) or D-4798-1P (182(H-R))
1STC Document SetSA04643CH



Order Part # G3F20165STP (80″ Diameter) Kit Includes:

  • NorthPoint Cessna…………………………………………………………………………..182(Q, R)…………………………………………………………………………………O-470-50
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-G3YF-1N/NM8411-6/30
1Polished SpinnerD-4798-3P (182,182(A-G)) or D-4798-1P (182(H-R))
1STC Document SetSA04643CH

Applicable Models: 182, 182(A-R)

Specifications:

  • Applicable engines: O-470-50, IO-520-D, IO-550-D
  • 2400 hour / 6 year TBO
  • 80″ or 82″ diameter 3-bladed aluminum hub, carbon fiber propeller
  • 80″: 64.4 pounds (propeller and D-4798-3P spinner)
  • 82″: 64.6 pounds (propeller and D-4798-3P spinner)
  • 82″: 63.8 pounds (propeller and D-4798-1P spinner)
  • NO RPM RESTRICTIONS

Interested in more information? Fill out the form below and we’ll contact you shortly.
