Manufacturer: Cessna
Aircraft Model(s): T206H
Applicable Engines: TIO-540-AJ1A
PDF: CESSNA T206H, SA03162CH (F3R00601STP, F3R00651STP)
| QTY | DESCRIPTION | ITEM # |
| 1 | 3-Bladed Propeller | HC-F3YR-1ARF/F8068 |
| 1 | Polished Spinner | D-4578-1P |
| 1 | STC Document Set | SA03162CH |
| DESCRIPTION | ITEM # | NOTES |
| Propeller with De-Ice Boots | HC-F3YR-1ARF/F8068K | |
| Airframe de-ice kit | 104522 |
Applicable Models:
T206H
Specifications:
82 inch dia 3-bladed, Scimitar, aluminum, extended hub prop
Compatible De-ice (replaces 3 blade to 3 blade only)
2400 hour / 6 year TBO
86.0 pounds (propeller and spinner)
Diameter reduction allowable to 80 inches
Replaces:
McCauley C432 79 inch diameter 3-bladed propeller
Diameter reduction allowable to 77.0 inches
2400 hour / 6 year TBO
Advantages:
Improved climb performance – + 10% (60 fpm) over 79” McCauley
at maximum gross weight.
Better cruise performance than 79” McCauley (1-4 knots delta improves with altitude).
Noise – 81.2 dB(a) measured per FAR 36, Appendix G.
Compatible De-ice
