Cessna TU206(A-G) Scimitar "Carbon Voyager" - Hartzell Propeller
North America:1 (800) 942-7767 International:+1 (937) 778-4200
Search

Manufacturer: Cessna
Aircraft Model(s): TU206(A-G)
Applicable Engines: IO-520-(A,F)-CF, IO-550-N, IO-550-F, TSIO-520-M

PDF: TU206(A-G)

Advantages:

  • Increased takeoff and climb performance
  • Lightest 3 blade available
  • Unlimited Life Blades
  • Top Prop Warranty to first overhaul

Landplane/Floatplane

Order Part # C3F20170STP (80″ Diameter) Kit Includes:

  • Vitatoe Aviation……………………………………………………………………….TU206(A-F)………………………………………………………………………………….IO-520(A,F)-CF
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-C3YF-1N/NM8411-6/SM30
1Polished SpinnerA-2295-1P
1STC Document SetSA04643CH

Landplane/Floatplane

Order Part # C3F20171STP (80″ Diameter) Kit Includes:

  • Summit Aviation…………………………………………………………………………….TU206G………………………………………………………………………………………IO-550-N
QTY DESCRIPTION ITEM #
1 3-Bladed Propeller HC-C3YF-1N/NM8411-6/SM30
1 Polished Spinner A-2295-1P
1 STC Document Set SA04643CH



Landplane/Floatplane

Order Part #C3F20164STP (82″ Diameter) Kit Includes:

  • Davis Aviation…………………………………………………………………………..TU206(A-G)…………………………………………………………………………………………………..IO-550-F
  • RAM………………………………………………………………………………………………TU206(A-F)……………………………………………………………………………………………..TSIO-520-M
  • Vitatoe Aviation………………………………………………………………………TU206(A-F)………………………………………………………………………………………………IO-550-F-CF
  • Wipaire…………………………………………………………………………………………….TU206F………………………………………………………………………………………………TSIO-520-M
  • Summit Aviation…………………………………………………………………………TU206F……………………………………………………………………………………………………IO-550-N
QTY
DESCRIPTION
ITEM #
1
3-Bladed Propeller
HC-C3YF-1N/NM8411-4/SM30
1
Polished Spinner
A-2295-1P
1
STC Document Set
SA04643CH

Floatplane

Order Part #C3F20167STP (86″ Diameter) Kit Includes:

  • Davis Aviation…………………………………………………………………………..TU206(A-G)…………………………………………………………………………………………………..IO-550-F
  • RAM………………………………………………………………………………………………TU206(A-F)…………………………………………………………………………………………….TSIO-520-M
  • Vitatoe Aviation………………………………………………………………………..TU206(A-F)…………………………………………………………………………………………..IO-550-F-CF
  • Wipaire…………………………………………………………………………………………..TU206F……………………………………………………………………………………………….TSIO-520-M
  • Summit Aviation……………………………………………………………………….TU206F……………………………………………………………………………………………………..IO-550-N
QTY
DESCRIPTION
ITEM #
1
3-Bladed Propeller
 HC-C3YF-1N/NM8411/SM30
1
Polished Spinner
A-2295-1P
1
STC Document Set
SA04643CH

Applicable Models: TU206(A-G)

Specifications:

  • Applicable engines: IO-520-(A,F)-CF, IO-550-N, IO-550-F, TSIO-520-M
  • 80″, 82″, or 86″ diameter 3-bladed aluminum hub, Carbon Fiber Propeller
  • 2400 hour / 6 year TBO
  • 80″: 62.6 pounds (C-Hub propeller and A-2295-1P spinner)
  • 82″: 62.8 pounds (C-Hub propeller and A-2295-1P spinner)
  • 86″: 63.1 pounds(C-Hub propeller and A-2295-1P spinner)
  • NO RPM RESTRICTIONS

Interested in more information? Fill out the form below and we’ll contact you shortly.
