Cessna TU206(A-G), TP206(A-E) Scimitar "Carbon Voyager" - Hartzell Propeller
North America:1 (800) 942-7767 International:+1 (937) 778-4200
Search

Manufacturer: Cessna
Aircraft Model(s): TU206(A-G), TP206(A-E)
Applicable Engines: IO-520-(A,F)-CF, IO-550-N, TSIO-520-M, IO-550-F

PDF: TU206(A-G), (A-E)

Advantages:

  • Increased takeoff and climb performance
  • Lightest 3 blade available
  • Unlimited Life Blades
  • Top Prop Warranty to first overhaul

Landplane/Floatplane

Kit #J3F20164STP (80″ Diameter) Includes:

  • Vitatoe Aviation…………………………………………………………….TU206(A-F), TP206(A-E)………………………………………………………………………………IO-520-(A,F)-CF
QTYDESCRIPTIONITEM #
13-Bladed PropellerHC-J3YF-1N/NM8411-6/SM44
1Polished SpinnerC-4582-1P
1STC Document SetSA04643CH

Landplane/Floatplane

Kit #J3F20165STP (80″ Diameter) Includes:

    • Summit Aviation……………………………………………………………..TU206G………………………………………………………………………………………………. IO-550-N
    • RAM……………………………………………………………………………………TP206(A-E)…………………………………………………………………………………………TSIO-520-M
QTY DESCRIPTION ITEM #
1 3-Bladed Propeller HC-J3YF-1N/NM8411-4/SM44
1 Polished Spinner C-4582-1P
1 STC Document Set SA04643CH



Landplane/Floatplane

Order Part #J3F20163STP Kit (82″ Diameter) Includes:

  • Davis Aviation…………………………………………………………….TU206(A-G), TP206(A-E)…………………………………………………………………………………..IO-550-F
  • RAM……………………………………………………………………………….TU206(A-F), TP206(A-E)……………………………………………………………………………TSIO-520-M
  • Vitatoe Aviation…………………………………………………………TU206(A-F), TP206(A-E)…………………………………………………………………………….IO-550-F-CF
  • Wipaire………………………………………………………………………………………TU206F………………………………………………………………………………………………..TSIO-520-M
  • Summit Aviation……………………………………………………………………..TU206F……………………………………………………………………………………………….IO-550-N
QTY
DESCRIPTION
ITEM #
1
3-Bladed Propeller
HC-J3YF-1N/NM8411-4/SM44
1
Polished Spinner
C-4582-1P
1
STC Document Set
SA04643CH



Floatplane

Order Part #J3F20161STP Kit (86″ Diameter) Includes:

  • Davis Aviation…………………………………………………………………TU206(A-G), TP206(A-E)……………………………………………………………………….IO-550-F
  • RAM……………………………………………………………………………………………..TU206(A-F)…………………………………………………………………………………….TSIO-520-M
  • Vitatoe Aviation………………………………………………………………TU206(A-F), TP206(A-E)…………………………………………………………………..IO-550-F-CF
  • Wipaire…………………………………………………………………………………………..TU206F……………………………………………………………………………………….TSIO-520-M
  • Summit Aviation…………………………………………………………………………TU206F…………………………………………………………………………………………IO-550-N
QTY
DESCRIPTION
ITEM #
1
3-Bladed Propeller
HC-J3YF-1N/NM8411/SM44
1
Polished Spinner
C-4582-1P
1
STC Document Set
SA04643CH

Applicable Models: TU206(A-G), TP206(A-E)

Specifications:

  • Applicable engines: IO-520-(A,F)-CF, IO-550-N, TSIO-520-M, IO-550-F-CF
  • 80″, 82″, or 86″ diameter 3-bladed aluminum hub, Carbon Fiber Propeller
  • 2400 hour / 6 year TBO
  • 80″: 64.6 pounds (J-Hub propeller and C-4582-1P spinner)
  • 82″: 64.8 pounds (J-Hub propeller and C-4582-1P spinner)
  • 86″: 65.1 pounds (J-Hub propeller and C-4582-1P spinner)
  • NO RPM RESTRICTIONS
