Manufacturer: Mooney
Aircraft Model(s): M20R Ovation, Ovation II, Ovation III, M20S Eagle, and M20TN
Applicable Engines: IO-550-G, IO-550-G-AP as modified by STC SE02930AT, IO-550-N, and TSIO-550-G
PDF: MOONEY M20R, M20S, M20TN SA03024CH (J3F07507STP, J3F07550STP, J3F07551STP)
| QTY | DESCRIPTION | ITEM # |
| 1 | 3-Bladed Propeller | PHC-J3YF-1RF/F7498 |
| 1 | Polished Spinner | A-2295-10P |
| 1 | STC Document Set | SA03024CH |
| DESCRIPTION | ITEM # | NOTES |
| Kit with Anti-ice Boots | PHC-J3YF-1RF/F7498( ) | |
| Kit with Anti-ice Boots and 3-blade Slinger Kit | PHC-J3YF-1RF/F7498( ) |
Applicable Models:
M20R Ovation, Ovation II, Ovation III, M20S Eagle, and M20TN
Specifications:
76 inch diameter 3-bladed aluminum hub propeller
2400 hour / 6 year TBO
72.5 pounds (propeller and spinner)
Diameter reduction allowable to 74 inches
Replaces:
McCauley 2A32C239/90MC-15- 75 in. dia. 2-bladed prop
2400 hour / 6 year TBO
56.0 pounds (propeller and spinner)
McCauley 3A32C418/82NRC-9 – 73 in. dia. 3-bladed prop
2000 hour / 6 year TBO
76.6 pounds (propeller and spinner)
McCauley 2A34C241/82PGC-6 – 76 inch diameter 2-blade prop
2400 hour / 6 year TBO
68 pounds (propeller and spinner)
Hartzell PHC-J3YF-1RF/F7693DF( )-2 76” diameter prop
2400 hour / 6 year TBO
80 pounds (propeller and spinner)
Advantages:
Better take-off and climb performance compared to either McCauley option.
Same-as or better cruise compared to either McCauley
7% decrease in glide distance (model R & S). Glide distance is unchanged for M20TN.
Noise – No acoustic change.
Improved appearance, Scimitar-style blade
Diameter reduction allowable in event of tip damage
