Aviat Husky A-1 thru A-1C-180 and A-1C-200

Manufacturer: Aviat Husky
Aircraft Model(s): A-1 thru A-1C-180 and A-1C-200
Applicable Engines: O-360-C1G, -A1P (180 hp), or IO-360-A1D6 (200 hp) engines
PDF: Aviat Husky

Kit Includes:

QTY	DESCRIPTION	ITEM #
1	2-Bladed Propeller	HC-C2YR-1N/N8301-3 “Trailblazer”
1	Polished Spinner or	C-3568-P
1	Composite Spinner or	105656F1 (Matterhorn White)
1	Composite Spinner	105656F2 (Metallic Silver)
1	STC Document Set	SA11177SC

Applicable Models:
A-1, A-1A, A-1B, A-1C-180, A-1C-200

Specifications:
80 inch diameter 2-bladed, aluminum hub, ASC II Composite Blades
2400 hour / 6 year TBO
41.0 pounds (propeller only)

Replaces:
Hartzell HC-C2YK-1BF/F7666A 2-blade aluminum hub and blades
Diameter: Max. 76”, Min 72”
2400 hour / 6 year TBO
57.0 Pounds (w/metal spinner)

Hartzell HC-C2YR-1N/F7605 2-blade aluminum hub, ASCII Composite Blades
Diameter: Max. 76”, Min 72”
2400 hour / 6 year TBO
43.0 Pounds

Hartzell HC-C2YK-1BF/F8477-4 2-blade aluminum hub and blades
Diameter: Max. 80”, Min 78”
2400 hour / 6 year TBO
71.5 Pounds (with spinner and damper)
De-rated to 2600 RPM (175 HP for noise)

MTV-15-B/205-58
80.7 inch diameter 2-blade, wood propeller
.8 inch diameter reduction allowed
2400 Hours/6 years
47.5 Pounds
De-rated to 2600 RPM (175 HP for noise)

Advantages:
Allows engine to run at full power continuously (2700 RPM)
Improved take-off and climb performance
Decreased take-off distance
Approved at all gross weights
FAR 36 compliant – Measured 81.7 dB(a) on A-1C-180/200, Measured 78.1 dB(a) on A-1, A-1A & A-1B
Smoother idle
Light weight
High durability and lowest life cycle cost

Notes:
Composite Spinner is approx. 2.0 lb. lighter than the aluminum version.
