Maule M-5-235C, M-6-235, M-7-235, M-7-235A, M-7-235-B, M-7-235-C, MX-7-235, MT-7-235, M-8-235

Manufacturer: Maule
Aircraft Model(s): M-5-235C, M-6-235, M-7-235, M-7-235A, M-7-235-B, M-7-235-C, MX-7-235, MT-7-235, M-8-235
Applicable Engines: O-540-J1A5D, O-540-J3A5, and IO-540-W1A5(D)

PDF: Maule 235 2 blade, SA04320CH (C2R40508STP)

Kit Includes:

QTY	DESCRIPTION	ITEM #
1	2-Bladed Propeller	HC-C2YR-1N/N8301-3
1	Polished Spinner	A-2298-2P
1	STC Document Set	SA04320CH

Applicable Models:
M-5-235C, M-6-235, M-7-235, M-7-235A, M-7-235-B, M-7-235-C, MX-7-235, MT-7-235, M-8-235

Specifications:
80 inch diameter 2-bladed, aluminum hub, ASC II Carbon Composite Blades
2400 hour / 6 year TBO
41.0 pounds (propeller only) 5.1 (spinner only)

Replaces:

Hartzell HC-C2YR-1BF/F8468A-6R, or -8R aluminum hub and blades
Diameter: Max. 78, Min :76
2400 hour / 6 year TBO
52.0 Pounds (prop only)

Hartzell HC-C2YR-1BF/F8477D-6, aluminum hub and blades
Diameter: Max. 78, Min :76
2400 hour / 6 year TBO
57.0 Pounds (prop only)

Hartzell HC-C3YR-1BF/F7693(F), aluminum hub and blades
Diameter: Max. 78 Min :76
2400 hour / 6 year TBO
73.7 Pounds (prop only)

McCauley B3D32C414-C/G-82NDA-2, or -4
Diameter: Max. 80, Min :76
2400 hour / 6 year TBO
73.0 Pounds ( prop only)

McCauley B237C224-B/G-90RA-9
Diameter: Max. 81, Min :78
2400 hour / 6 year TBO
49.0 Pounds (prop only)

Advantages:
Improvements vary
Eliminates RPM limitation
Smoother operation
Light weight.
High durability and lowest life cycle cost, Unlimited life blades.
Best warranty in the industry and worldwide support.

Notes:
7:00 tires or larger/26 psi minimum air pressure required per Note.
14 of TC 3A23.
